appointment
Lighting of industrial rooms, storage rooms, exhibition centers, covered parking areas, sports grounds, hangars etc.
-
LEDs
-
Degree of protection
-
No flicker
-
It does not contain mercury
-
Without recycling of naste
-
I class of protection against electric shock
-
Color rendering index
-
Resistance to temperature changes
-
Voltage
-
Lifetime
| Specifications | LED-SVU-E-P-01(8W) STARK-500 |
| Power, W | 8 |
| Luminous flux, lm | 1168 |
| Scattering angle,° | 120 |
| Efficiency, Lm/w | 146 |
| Color temperature, K | 3200-5000 |
| Possible power range, V | AC 90-264, DC 127-370 |
| Environmental humidity, % | 10-90 |
| Сlimatic modification | ТU1 |
| Analogue | ЛОН-100 |
| Overall dimensions (LxBxH), mm | 530x85x160 |
| Weight, kg | 1,8 |
| Body material | anodized aluminum |
| IDC type |  |
| Manufacturing of luminaires with other technical characteristics is possible according to the customer's order | |
