appointment
The floodlight can be used for architectural lighting of buildings and structures, security lighting, illumination of billboards and shop windows, for lighting of warehouses and industrial premises, facades, buildings, exhibition complexes, closed parking lots, etc.
-
LEDs
-
Degree of protection
-
No flicker
-
It does not contain mercury
-
Without recycling of naste
-
I class of protection against electric shock
-
Color rendering index
-
Resistance to temperature changes
-
Voltage
-
Lifetime
| Specifications | LED-SVU-P-W2-18(500W)GRAND MAX 2M ASYMMETRIK |
| Power, W | 500 |
| Luminous flux, lm | 80000/75000 |
| Scattering angle,° | 120/15,30,60,90 |
| Efficiency, Lm/w | 160/150 |
| Color temperature, K | 3000-5000 |
| Possible power range, V | AC 100-305, DC 142-431 |
| Environmental humidity, % | 10-90 |
| Сlimatic modification | U1 |
| Overall dimensions (LxBxH), mm | 570x665x155 |
| Weight, kg | 25,1/26 |
| Body material | anodized aluminum |
| IDC type - D (120) |  |
| IDC type - K (15) |  |
| IDC type - K (30) |  |
| IDC type - G (60) |  |
| IDC type - G (90) |  |
| Manufacturing of luminaires with other technical characteristics is possible according to the customer's order | |
